4. The fifth group of data: transmission mode, IO driving method, wireless wake-up time, transmit power (bit2
is not used and default as 0)
Transmission Mode
IO Driven Mode
Wake-up Time
(ms)
Transmit Power
(dBm)
In Binary
In Hex
Transparent transmission
Open circuit output
250
20
0 0 000 0 00
00
Transparent transmission
Open circuit output
1000
20
0 0 011 0 00
18
Transparent transmission
Open circuit output
2000
20
0 0 111 0 00
38
Transparent transmission
Push-pull output
250
20
0 1 000 0 00
40
Transparent transmission
Push-pull output
1000
20
0 1 011 0 00
58
Transparent transmission
Push-pull output
1500
20
0 1 101 0 00
68
Transparent transmission
Push-pull output
2000
20
0 1 111 0 00
78
Fixed point transmission
Open circuit output
250
20
1 0 000 0 00
80
Fixed point transmission
Open circuit output
1000
20
1 0 011 0 00
98
Fixed point transmission
Open circuit output
1500
20
1 0 101 0 00
A8
Fixed point transmission
Push-pull output
2000
20
1 1 111 0 00
F8
Fixed point transmission
Push-pull output
250
20
1 1 000 0 00
C0
Fixed point transmission
Push-pull output
1000
20
1 1 011 0 00
D8
Fixed point transmission
Push-pull output
2000
20
1 1 111 0 00
F8
