S3
NETID
Network ID.
25
255
0
Yes
S4
TXPOWER
1
Transmit power in dBm.
30
30
0
No
S5
ECC
2
Enables or disables the Golay error
correcting code.
0
1
0
Yes
S6
MAVLINK
3
Enables or disables the MAVLink framing
and reporting
1
1
0
No
S7
OP_RESEND
Opportunistic resend allows the node to
resend packets if it has spare bandwidth
0
1
0
No
S8
MIN_FREQ
1
Min frequency in KHz
915000
/868000
4,8
927000
/870000
4
902000
/865000
4,8
Yes
S9
MAX_FREQ
1
Max frequency in KHz
928000
/870000
4
928000
/870000
4
903000
/865000
4,8
Yes
S10
NUM_CHANNELS
1
Number of frequency hopping channels
20/1
4,8
51
8
/8
4,8
1
Yes
S11
DUTY_CYCLE
1
The percentage of time to allow transmit
100
100
10
No
S12
LBT_RSSI
1
Listen before talk threshold
0
220
25
Yes
S13
RTSCTS
Ready-to-send and Clear-to-send flow
control.
0
1
0
No
S14
Max Window
Max transit window size used to limit max
time/latency if required otherwise will be
set automatically
131
400
20
Yes
S15
Encryption Level
Encryption level 0=off, 1=128bit AES
0
1
0
Yes
S16
GPIO1.1 R/C input
Set GPIO 1.1 (pin 15) as R/C(PPM) input
0
1
0
No
S17
GPIO1.1 R/C output
Set GPIO 1.1 (pin 15) as R/C(PPM) output
0
1
0
No
S18
GPIO1.1 SBUS input
7
Set GPIO 1.1 (pin 15) as R/C(PPM) input
0
1
0
No
S19
GPIO1.1 SBUS output
7
Set GPIO 1.1 (pin 15) as R/C(PPM) output
0
1
0
No
S20
ANT_MODE
0= Diversity, 1= Antenna 1 only, 2=
Antenna 2 only, 3= Antenna 1 TX and
antenna 2 RX
0
3
0
No
Reg
#
S Register
Description
Default
Value
Maximum
Value
Minimum
Value
Must be the same
at both ends of
the link?
S21
GPIO1.3 Status LED output
0
1
0
No
