RFDesign RFD TXMOD - 1 Introduction; Product Description; Getting to Know the Product

RFD TXMOD User Manual
www.rfdesign.com.au
– Version 1.2 – Status – Issued for use
Document Number – PRJ-TXM-MAN-001
Page
2
1 Introduction
1.1 Product Description
The RFD TXMOD, or TXMOD, has been designed to work in conjunction with the Taranis X9D Radio
Control Transmitter from FrSky and other compatible controllers. The RFD TXMOD transmits the
PPM stream from the controller to the vehicle via the RF Design long range telemetry modems while
also receiving telemetry data from the aircraft. The telemetry data can be broadcast to a computer
or smart device by the TXMOD’s built in Wi-Fi module.
1.2 Getting to know the product
Figure 2 - TXMOD top (left) and bottom (right) views
Figure 1 - Typical Application Diagram.
