Table 6 - Networking and Security
Addressing Options
Network ID: 0 –255
Channels
Up to 50 Frequency Hopping Channels
Supported Network Topologies
Point to point
6.3 Wi-Fi Specifications
Table 7 - Wi-Fi Parameters
Wi-Fi Protocols
802.11 b/g/n
Frequency Range
2.4GHz-2.5GHz (2400MHz-2483.5MHz)
Wi-Fi mode
station/softAP/
Security
WPA/WPA2
Encryption
WEP/TKIP/AES
Firmware Upgrade
OTA (via network)
Network Protocols
IPv4, TCP/UDP/HTTP/FTP
User Configuration
Browser interface
Table 8 – Wi-Fi Transceiver Characteristics
Parameters
Min
Typical
Max
Unit
Input frequency
2412
2484
MHz
Input impedance
50
Ω
Input reflection
-10
dB
Output power of PA for 72.2Mbps
15.5
16.5
17.5
dBm
Output power of PA for 11b mode
19.5
20.5
21.5
dBm
Sensitivity
DSSS, 1 Mbps
-98
dBm
CCK, 11 Mbps
-91
dBm
6 Mbps (1/2 BPSK)
-93
dBm
54 Mbps (3/4 64-QAM)
-75
dBm
HT20, MCS7 (65 Mbps, 72.2 Mbps)
-72
dBm
Adjacent Channel Rejection
OFDM, 6 Mbps
37
dBm
OFDM, 54 Mbps
21
dBm
HT20, MCS0
37
dBm
HT20, MCS7
20
dBm
