f) Wi-Fi Troubleshooting:
In some cases, user connection settings may prevent devices from accessing the Wi-Fi addresses.
Some basic troubleshooting.
- Remove the existing network settings from the device memory
- Reset the wireless adaptor
- Turn off mobile data and disconnect other networking devices such as LAN cables.
- In other cases, OS tools such as the Windows Network Diagnostics may help.
If you forget your settings or the device is not available on the network, it is possible to reset the
TXMOD to its default Wi-Fi settings.
- Pressing the button 5 times rapidly while the device is powered up to initiate a factory reset of the
TXMOD and the internal modem.
- Set up the device again as per earlier instructions.
3.2.3 TXMOD Internal RFD900x Modem settings
The TXMOD has an RFD900x series modem internally pre-configured with factory parameters, see
figure 12. A description of this parameters can be found in Table 3 - RFD900x parameters. For
further information regarding the internal modem refer to the RFD900x Peer to Peer Firmware and
RFDesign Modem 900x Datasheet documents using the links in section 7.
Table 3 - RFD900x parameters from RFD900x Peer-to-peer V3.X User Manual V1.3.pdf
Must be the same
at both ends of
the link?
FORMAT
This is for EEPROM version, it should not
be changed. It is set by the firmware
SERIAL_SPEED
Serial speed in ‘one-byte form’. Accepted
values are 1, 2, 4, 9, 19, 38, 57, 115, 230,
460 and 1000 corresponding to 1200bps,
2400bps, 4800bps, 9600bps, 19200bps,
38400bps, 57600bps, 115200bps,
230400bps, 460800bps and 1000000bps
respectively.
AIR_SPEED
1
Air data rate in ‘one-byte form’. Accepted
values are 12, 56, 64, 100, 125, 200, 224,
500 and 750 corresponding to 12000bps,
56000bps 64000bps, 100000bps,
125000bps, 200000bps, 250000bps,
224000bps, 500000bps and 750000bps
respectively.
Must be the same
at both ends of
the link?
