Rheem 325 II Series User Manual

6
This document is stored and maintained electronically by Service. All printed copies are deemed uncontrolled.
TM077: 325 & 410 Series II Heat Pump Service Instructions
Rev 00: Issued April 2014
SPECIFICATIONS
Storage Tank
Parameter
Model
T551410
1
T554410
1, 3
T251410
1
T451325
T551325
T554325
3
T251325
T325HAV
HP325S36
Capacity (Litres)
410
325
325
325
Boost Capacity (Litres)
200
2
180
2
100 / 180
2
206
Booster Element Rating (kW)
2.4 / 3.6
1.8 / 2.4 / 3.6
1.8 / 2.4 / 3.6
3.6
T&PR Valve Rating (kPa)
1000
1000
1000
1000
Maximum Inlet Water
Pressure (kPa)
With ECV
680
680
680
650
Without ECV
800
800
800
850
Water Connections
Inlet / Outlet
Rp ¾” (20mm)
Rp ¾” (20mm)
Rp ¾” (20mm)
Rp ¾” (20mm)
Heat Pump
Rp ½” (15mm)
Rp ½” (15mm)
Rp ½” (15mm)
Rp ½” (15mm)
T&PR
Rp ½” (15mm)
Rp ½” (15mm)
Rp ½” (15mm)
Rp ¾” (20mm)
Anode
Quantity
1
1
1
1
Length (mm)
1596
1340
1370
1480
Booster Element Thermostat Setting
(Fixed)
70ºC
70ºC
70ºC
70ºC
Booster Element ECO Setting
85ºC
85ºC
85ºC
84ºC
1
410L model for use in QLD only.
2
Boost volume with droopy element fitted – droopy element available in 2.4kW and 3.6kW only.
3
RheemPlus models have the mains terminal block and earth connection on the opposite side of the tank to the heat pump module. RheemPlus
models therefore have three electrical covers on the storage tank.

Rheem 325 II Series Specifications

General

Brand	Rheem
Model	325 II Series
Category	Heat Pump
Language	English
