Rheem RHPD Series User Manual

66
ST-A1273-26-00
89”
[2261 mm]
57 7/8”
[1470 mm]
ACCESS PANEL
HEAT EXCHANGER
ACCESS PANEL
BLOWER
ACCESS PANEL COMPRESSOR
CONTROL ACCESS
120 MODEL
60”
[1524 mm]
090 THRU 102
MODELS
50”
[1270 mm]
RETURN COVER
SUPPLY COVER
DRAIN PAN
SERVICE DISCONNECT
KNOCKOUT
FIGURE 2
UNIT DIMENSIONS
ST-A1273-01_D-00
SERVICE
PORT
DOOR
POWER
ENTRY
RECEPTACLE
29 1/4”
[743 mm]
32 3/4”
[832 mm]
90 1/8”
[2289 mm]
59 1/2”
[1511 mm]
3 3/4”
[97 mm]
FILTER
A
CCESS PANEL
INDOOR COIL
A
CCESS PANEL
4 1/4”
[110 mm]
FIGURE 1
UNIT DIMENSIONS AND ACCESS LOCATIONS
