Rheem RHPD Series User Manual

8
GENERAL DATA
NOTES:
1. Cooling Performance is rated at 95° F ambient, 80° F entering dry bulb, 67° F entering wet bulb. Gross capacity does not include the effect of fan motor heat. AHRI capaci-
ty is net and includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Units are certied in accordance with the Unitary Air Conditioner
Equipment certication program, which is based on AHRI Standard 210/240 or 360.
2. EER and/or SEER are rated at AHRI conditions and in accordance with DOE test procedures.
3. Integrated Part Load Value is rated in accordance with AHRI Standard 210/240 or 360. Units are rated at 80° F ambient, 80° F entering dry bulb, and 67° F entering wet
bulb at AHRI rated cfm.
4. Outdoor Sound Rating shown is tested in accordance with AHRI Standard 270.
Model RHPDZS Series 090ACA 090ACB 090ACC 090ACF
Cooling Performance1 Continued ->
Gross Cooling Capacity Btu [kW] 89,000 [26.08] 89,000 [26.08] 89,000 [26.08] 89,000 [26.08]
EER/SEER2 11/NA 11/NA 11/NA 11/NA
Nominal CFM/AHRI Rated CFM [L/s] 3000/3030 [1416/1430] 3000/3030 [1416/1430] 3000/3030 [1416/1430] 3000/3030 [1416/1430]
AHRI Net Cooling Capacity Btu [kW] 86,000 [25.2] 86,000 [25.2] 86,000 [25.2] 86,000 [25.2]
Net Sensible Capacity Btu [kW] 62,800 [18.4] 62,800 [18.4] 62,800 [18.4] 62,800 [18.4]
Net Latent Capacity Btu [kW] 23,200 [6.8] 23,200 [6.8] 23,200 [6.8] 23,200 [6.8]
IEER3 12.2 12.2 12.2 12.2
Net System Power kW 7.55 7.55 7.55 7.55
Heating Performance (Heat Pumps)
High Temp. Btuh [kW] Rating 84,000 [24.61] 84,000 [24.61] 84,000 [24.61] 84,000 [24.61]
System Power KW / COP 6.84/3.3 6.84/3.3 6.84/3.3 6.84/3.3
Low Temp. Btuh [kW] Rating 48,000 [14.06] 48,000 [14.06] 48,000 [14.06] 48,000 [14.06]
System Power KW / COP 6.44/2.26 6.44/2.26 6.44/2.26 6.44/2.26
Compressor
No./Type 1/Scroll 1/Scroll 1/Scroll 1/Scroll
Outdoor Sound Rating (dB)5 88 88 88 88
Outdoor Coil - Fin Type Louvered Louvered Louvered Louvered
Tube Type MicroChannel MicroChannel MicroChannel MicroChannel
MicroChannel Depth in. [mm] 1 [25.4] 1 [25.4] 1 [25.4] 1 [25.4]
Face Area sq. ft. [sq. m] 22.8 [2.12] 22.8 [2.12] 22.8 [2.12] 22.8 [2.12]
Rows / FPI [FPcm] 1 / 16 [6] 1 / 16 [6] 1 / 16 [6] 1 / 16 [6]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Indoor Coil - Fin Type Louvered Louvered Louvered Louvered
Tube Type MicroChannel MicroChannel MicroChannel MicroChannel
MicroChannel Depth in. [mm] 1.26 [32] 1.26 [32] 1.26 [32] 1.26 [32]
Face Area sq. ft. [sq. m] 10.9 [1.01] 10.9 [1.01] 10.9 [1.01] 10.9 [1.01]
Rows / FPI [FPcm] 1 / 20 [8] 1 / 20 [8] 1 / 20 [8] 1 / 20 [8]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/0.75 [19.05] 1/0.75 [19.05] 1/0.75 [19.05] 1/0.75 [19.05]
Outdoor Fan - Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 2/24 [609.6] 2/24 [609.6] 2/24 [609.6] 2/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 8000 [3775] 8000 [3775] 8000 [3775] 8000 [3775]
No. Motors/HP 2 at 1/2 HP 2 at 1/2 HP 2 at 1/2 HP 2 at 1/2 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan - Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/15x15 [381x381] 1/15x15 [381x381] 1/15x15 [381x381] 1/15x15 [381x381]
Drive Type Belt (Adjustable) Belt (Adjustable) Belt (Adjustable) Belt (Adjustable)
No. Speeds Single Single Single Single
No. Motors 1 1 1 1
Motor HP 2 3 3 2
Motor RPM 1725 1725 1725 1725
Motor Frame Size 56 56 56 56
Filter - Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(NO.) Size Recommended in. [mm x mm x mm] (4)2x20x20 [51x508x508] (4)2x20x20 [51x508x508] (4)2x20x20 [51x508x508] (4)2x20x20 [51x508x508]
Refrigerant Charge Oz. [g] 179 [5075] 179 [5075] 179 [5075] 179 [5075]
Weights
Net Weight lbs. [kg] 775 [352] 785 [356] 786 [357] 775 [352]
Ship Weight lbs. [kg] 814 [369] 824 [374] 825 [374] 814 [369]
