IX. ELECTRICAL DATA - RKNL
ELECTRICAL DATA - RKNL SERIES
Unit Operating Voltage
Range
Volts
Minimum Circuit
Ampacity
Minimum Overcurrent
Protection Device Size
Maximum Overcurrent
Protection Device Size
Unit Information
No.
Volts
Phase
RPM
HP, Compressor 1
Amps (RLA), Comp. 1
Amps (LRA), Comp. 1
HP, Compressor 2
Amps (RLA), Comp. 2
Amps (LRA), Comp. 2
Compressor Motor
B180CL/ B180CM/ B180DL/ B180DM/ B180YL/ B180YM/ B210CL/ B210CM/ B210DL/ B210DM/
C180CL/ C180CM/ C180DL/ C180DM/ C180YL C180YM C210CL/ C210CM/ C210DL/ C210DM/
H180CR H180CS H180DR H180DS H210CR H210CS H210DR H210DS
187-253 187-253 414-506 414-506 518-632 518-632 187-253 187-253 414-506 414-506
208/230 208/230 460 460 575 575 208/230 208/230 460 460
78/78 81/81 38 40 28 30 88/88 91/91 44 46
90/90 90/90 45 45 30 35 100/100 100/100 50 50
100/100 100/100 45 50 35 35 110/110 110/110 50 50
2 2 2 2 2 2 2 2 2 2
200/230 200/230 460 460 575 575 200/230 200/230 460 460
3 3 3 3 3 3 3 3 3 3
3450 3450 3450 3450 3450 3450 3450 3450 3450 3450
7 7 7 7 7 7 7 1/2 7 1/2 7 1/2 7 1/2
25/25 25/25 12.2 12.2 9 9 29.5/29.5 29.5/29.5 14.7 14.7
164/164 164/164 100 100 78 78 195/195 195/195 95 95
7 7 7 7 7 7 7 1/2 7 1/2 7 1/2 7 1/2
25/25 25/25 12.2 12.2 9 9 29.5/29.5 29.5/29.5 14.7 14.7
164/164 164/164 100 100 78 78 195/195 195/195 95 95
4 4 4 4 4 4 4 4 4 4
208/230 208/230 460 460 575 575 208/230 208/230 460 460
1 1 1 1 1 1 1 1 1 1
1/3 1/3 1/3 1/3 1/3 1/3 1/3 1/3 1/3 1/3
2.4/2.4 2.4/2.4 1.4 1.4 1 1 2.4/2.4 2.4/2.4 1.4 1.4
4.7/4.7 4.7/4.7 2.4 2.4 1.8 1.8 4.7/4.7 4.7/4.7 2.4 2.4
1 1 1 1 1 1 1 1 1 1
208/230 208/230 460 460 575 575 208/230 208/230 460 460
3 3 3 3 3 3 3 3 3 3
3 5 3 5 3 5 3 5 3 5
11.5/11.5 14.9/14.9 4.6 6.6 3.5 5.3 11.5/11.5 14.9/14.9 4.6 6.6
74.5/74.5 82.6/82.6 38.1 46.3 20 39.4 74.5/74.5 82.6/82.6 38.1 46.3
No.
Volts
Phase
HP
Amps (FLA, each)
Amps (LRA, each)
Condenser Motor
No.
Volts
Phase
HP
Amps (FLA, each)
Amps (LRA, each)
Evaporator Fan
