53
FIGURE 38
RKNL-H SERIES
208V
15
208V
13
208V
13
208V
13
INDUCER VOLTAGE CHANGE (208/240V):
UPLUG BLACK WIRE FROM INDUCER. MOVE
INSULATED PLUG FROM (RED) WIRE TO
(BLK) WIRE. PLUG INDUCER (RED) WIRE
INTO (BLK) WIRE.
TRANSFORMER AND INDUCERS
FACTORY WIRED FOR 230 VOLTS.
15
01
ADDED RED 208V LEAD TO IDM’S, REVISED NOTE 3, ADDED NOTE 15.
VYM
Y-0655S251
04-04-18
01
