8
FIGURE 7
COMPONENT ACCESS
LOCATIONS & DIMENSIONS
ST-A1125-03
OUTDOOR FAN #4
OUTDOOR FAN #1
OUTDOOR FAN #2
OUTDOOR FAN #5
OUTDOOR FAN #3
OUTDOOR FAN #6
1
2
3
6
5
4
OUTDOOR COIL
HEAT EXCHANGER
FILTER RACK
RETURN COMPARTMENT
FIGURE 8
COMPONENT LOCATIONS
ST-A1125-05
ST-A1125-08A
FIGURE 6
DIMENSIONS
(REAR SIDE)
*RECOMMENDED DUCT CONNECTION SIZE
SUPPLY: 24 x 40.8 INCHES
RETURN: 47 x 20 INCHES
