RHINO PelcoD 2400bps on RS485 - Securview VSPTZ55(W) PTZ Configuration; Power Connection Details; RS485 Communication Setup; ID Setting Switch Configuration

Securview VSPTZ55(W) PTZ on ID01 and Pelco-D at 2400Bps
For Power Connection:
24vAC+ Red
24vAC- Black
For 2 wire RS485 Connection:
RS485+ Orange (Rx+)
RS485- Yellow (Rx-)
ID Setting Switch
1 2 3 4 5 6 7 8 9 10
Ï Ð Ð Ð Ð Ð Ð Ð Ð Ð
Protocol Setting
1 2 3 4 5
Ð Ð Ï Ð Ð
