RHINO PelcoD 2400bps on RS485 - Vsptzkb

Securview VSPTZKB on ID01 and Pelco-D at 2400Bps
For Power Connection:
12vDC Socket
For 2 wire RS485 connection:
RS485+ (Tx+)
RS485- (Tx-)
There are 2 sets are Tx- and Tx+, either can be used.
Protocol Switch
1 2 3 4 5 6 7 8
Ð Ï Ï Ï Ï Ï Ï Ï
© Copyright 2009 RhinoCo Technology Page 5
