JVC TK-C686WPE PTZ on ID01 and Pelco-D at 2400Bps

For Power Connection:

24vAC+ Red

24vAC- Black

For 2 wire RS485 connection:

RS485+ Orange/White (Rx+)

RS485- Black/White (Rx-)

Setting Switch

1 2 3 4 5 6 7 8

Ï Ð Ð Ð Ð Ð Ð Ð

Machine ID

1 2 3 4 5 6 7 8

Ï Ð Ð Ð Ð Ð Ð Ð

Option Switch

1 2 3 4 5 6 7 8

Ð Ð Ð Ð Ð Ï Ð Ð

To access to onboard menu:

Press PRESET > 9 > 5 > ENTER

MENU = Close

SET = Open
