A-FRAME ASSEMBLY TM100
ITEM PART NO. QTY. DESCRIPTION
1 00779999 1 FLAT,DRIVELINE HOLDER
2 00779751 2 WDMT,LOWER LINK - TM100
3 00786022 1 ARM,FRONT A-FRAME - LH TM100
00786021 1 ARM,FRONT A-FRAME - RH TM100 (NOT SHOWN)
4 00779659 2 ARM,UPPER LINK - TM100
5 00779644 2 ARM,REAR A-FRAME - TM100
6 00748823 5 HHCS 1/2-13UNC 1-1/2 PL5
7 00001800 14 LOCKNUT TLM 1/2 NC PLB
8 00779848 2 BUSHING,LOWER A-FRAME
9 00779850 1 BUSHING,TOP LINK
10 00001400 9 FLATWASHER 5/8 PL STD
11 00695100 12 LOCKNUT TOPLOCK 5/8NC PLB
12 00779867 6 BUSHING,UPPER LINK
13 00779869 1 PIN,TOP LINK
14 37107B13 1 CLIP-X HAIR PIN (NOT SHOWN)
15 02957007 1 HHCS 5/8 NC 5 PL8
16 00779868 2 PIN,CAT I-II QH
©2014 Alamo Group Inc. Parts Section -4
TM60 TM72 TM84 TM100
