ELECTRONIC CONTROL FOR TERMINAL UNITS
11
II SECTION II: INSTALLATION
II.1 INSTRUCTION FOR TRANSPORT
II.1.1 PACKAGING AND COMPONENTS
DANGER!
Do not open or tamper with the package up to the
point of installation.
Upon delivery, check that the accessory has not been damaged during
transport and that it is complete with all its parts.
If there is visible damage, immediately take note of the damage and
write this on the transport document together with the following
statement: “ACCEPTED WITH RESERVATIONS BECAUSE OF
EVIDENT DAMAGE TO THE PACKAGING”, stating the serial number if
there are several machines, since ex-works delivery implies entitlement
to compensation under the terms of the insurance, in accordance with
the provisions of Law no. 450 of 22/08/85 “limit of compensation”.
Follow these instructions to remove the packaging:
Check for visible damage;
Open the packaging;
Dispose of the packaging material in accordance with current
legislation, at the appropriate waste reception or recycling site.
SAFEGUARD THE ENVIRONMENT!
Dispose of the packaging materials in compliance
with the national or local legislation in force in your
country.
DANGER!
Do not leave the packaging within reach of children.
II.1.2 HANDLING GUIDELINES
DANGER!
Movement of the unit must be performed with care,
in order to avoid damage to the external structure
and to the internal mechanical and electrical
components.
Also make sure that there are no obstacles or
people along the way, to avoid the danger of
collisions, crushing or overturning of the lifting
equipment.
All the operations listed below must be carried out in accordance with
current health and safety regulations, with reference to the equipment
used as well as the procedures followed.
II.1.3 STORAGE CONDITIONS
The packaged units can be stored by stacking no more than four units
and must be stored in dry conditions and protected from the sun and
rain.
II.1.4 SPACES OF RESPECT, POSITIONING
IMPORTANT!
Incorrect positioning or installation of the unit may
amplify noise levels and vibrations generated
during operation.
II.2 INSTALLATION INSTRUCTIONS
DANGER!
The installation must be performed exclusively by
expert technicians authorized to work on air
conditioning and refrigeration products. Incorrect
installation could cause the unit to run badly, with a
consequent deterioration in performance.
DANGER!
Personnel are obliged to follow local or national
regulations in force when the machine is installed.
II.3 ASSEMBLY OF THE KIT
DANGER!
When assembling the kit, pay attention to the sharp
edges of the card holder and the heat exchange
coil, as they can cause cuts due to improper use.
Use suitable individual protections (gloves,
glasses, etc.).
Refer to the instruction sheet inside the kits.
II.3.1 ELECTRICAL CONNECTIONS
IMPORTANT!
The electrical connection of the unit must be
carried out by qualified personnel, in compliance
with the regulations applicable in the country where
the unit is installed. A non-compliant electrical
connection lifts RHOSS Spa from liability
concerning damage to objects and persons.
DANGER!
Always install in the protected area and near the
machine a general automatic switch with delayed
characteristic curve, of adequate capacity and
breaking capacity and with a minimum contact
opening distance of 3 mm.
Earth connection is compulsory by law to ensure
user safety while the machine is in use.
Strip off the sheathing only in the immediate area of the terminals. Use
suitable cable-ends for the terminals involved.
After inserting the cable terminal into the clamp, tighten the screws with
a screwdriver without tightening them with excessive force: when the
operation is completed, slightly pull the cables to check that they are
tight.
Use a band to lock the cables inside the electronic board compartment.
