RIB K400 - Table Summarising Alarms and Visual and Sound Signals; Signals During Programming Sequence

TABLE SUMMARISING ALARMS AND VISUAL AND SOUND SIGNALS
SIGNALS DURING PROGRAMMING SEQUENCE
EVENT BUZZER STATUS FLASHER STATUS PROGRAMMING LED DL1 STATUS
DIP 1 ON (HOLD MODE)
OR FAILURE OF A SAFETY DEVICE (ON
STEADY MODE)
OFF OFF FLASHES ON-OFF 250 MS
DIP 2 ON (FULL STROKE PROGRAMMING) OFF OFF FLASHES ON-OFF 500 MS
DIP 2>1 ON (PEDESTRIAN STROKE
PROGRAMMING)
OFF OFF FLASHES ON-OFF 500 MS
PROGRAMMING SEQUENCE STOPPED DUE
TO INTERVENTION OF A SAFETY DEVICE
OFF OFF ON STEADY
EVENT BUZZER STATUS FLASHER STATUS TWO-COLOUR DL10 LED STATUS (FOR REMOTE
CONTROL PROG.)
NO REMOTE CONTROL CODE ENTERED OFF OFF FLASHES INTERMITTENTLY RED/GREEN
DIP 1 > 2 - FULL OPENING REMOTE
CONTROL CODE PROGRAMMING
OFF OFF FLASHES RED FOR 10 SECONDS
DIP 1 > 3 - PEDESTRIAN OPENING REMOTE
CONTROL CODE PROGRAMMING
OFF OFF FLASHES GREEN FOR 10 SECONDS
FULL OPENING REMOTE CONTROL CODE
PROGRAMMING, OUTCOME OK
1 TONE OFF TURNS GREEN ONCE
PEDESTRIAN OPENING REMOTE CONTROL
CODE PROGRAMMING, OUTCOME OK
1 TONE OFF TURNS RED ONCE
REMOTE CONTROL CODE NOT PRESENT IN
MEMORY
OFF OFF RED FLASH
MEMORY SATURATED BY REMOTE CONTROL
CODES (1000 CODES SAVED)
OFF OFF RUNS 6 GREEN FLASHES
FULL OPENING CODE DELETION 2 TONES OFF RUNS 2 RED FLASHES
PEDESTRIAN OPENING CODE DELETION 2 TONES OFF RUNS 2 GREEN FLASHES
WARNING SIGNALS DURING OPERATION
EVENT BUZZER STATUS FLASHER STATUS LED STATUS AND SIGNAL OUTPUT
STOP BUTTON PRESSED OFF OFF LED DL12 TURNS OFF
PHOTOCELL INTERVENTION 1 TONE OFF LED DL13 TURNS OFF
EDGE INTERVENTION 2 TONES OFF LED DL14 TURNS OFF
CURRENT SENSOR ENABLED 3 TONES OFF NO LED COMBINED
FAILURE OF A SAFETY DEVICE OR SAFETY
DEVICE ENGAGED FOR TOO LONG
OFF OFF LED DL1 FLASHES ON-OFF 250 MS
RUNNING WITH EMERGENCY BATTERIES
(24 Vdc)
OFF CURRENTLY ENABLED SIGNAL OUTPUT FLASHES ON-OFF TWICE FOR
250 MS FOLLOWED BY A PAUSE OF 2 SECONDS
EMERGENCY BATTERIES LOW SIGNAL 1 TONE EVERY 5 SECONDS FOR 1 MINUTE
(RESET BY ACTIVATING A CONTROL)
OFF SIGNAL OUTPUT FLASHES CONTINUOUSLY ON-
OFF FOR 500 MS
ALARM FROM EDGE 2 TONES EVERY 5 SECONDS FOR 1 MINUTE
(RESET BY ACTIVATING A CONTROL)
ENABLED FOR 1 MINUTE (FLASHING) NO LED COMBINED
CURRENT SENSOR ALARM 3 TONES EVERY 5 SECONDS FOR 1 MINUTE
(RESET BY ACTIVATING A CONTROL)
ENABLED FOR 1 MINUTE (FLASHING) NO LED COMBINED
FAILED AUTO-TEST ALARM 4 TONES EVERY 5 SECONDS FOR 1 MINUTE
(RESET BY ACTIVATING A CONTROL)
OFF NO LED COMBINED
ENCODER FAILURE ALARM 5 TONES EVERY 5 SECONDS FOR 1 MINUTE
(RESET BY ACTIVATING A CONTROL)
OFF LED DL2 OFF
MEMORY NOT INSERTED ALARM 3 SECONDS ON - 3 SECONDS OFF
TURNS OFF ONLY WHEN THE MEMORY IS
INSERTED
OFF NO LED COMBINED
INCORRECT SELF-DIAGNOSTIC ALARM CONTINUOUS TONE FOR 10 SECONDS WITH
A PAUSE OF 2 SECONDS OFF
TURNS OFF ONLY IF DIP 2 IS SET TO OFF
OFF LED DL1 ON STEADY
FUNCTIONAL BLOCK OFF OFF TWO-TONE LED DL10 IS ON STEADY (ORANGE).
