RIB K400 - Maintenance and Electrical Connections; Electric Connection Diagram

ELECTRIC CONNECTIONS
K 24V-CRX cod. AC08006
G
B
0
24Vdc 20W
24Vac
10Vac
ANTENNA
433 MHz
STOP
24Vdc 0,4A ±15%
24Vdc 0,4A ±15%
TIMER
ENCODER
M
L.S. OPEN
AND CLOSE
FUSE
T 1,6A
POWER SUPPLY
230Vac 50Hz
TRANSFORMER
ANTENNA BRAIDING
COMMON
PHOTOCELLS
EDGE
OPEN
CLOSE
SINGLE COMMAND
PEDESTRIAN
24Vdc 10W
BACKUP BATTERIES
FOR BATTERY CHARGER
BOARD (OPTIONAL)
A+TEST / A-
SAFETY DEVICE
AUTO-TEST OR
ENERGY SAVING
(LOW POWER) WITH
BATTERY OPERATION
MANUAL
RELEASE
SAFETY
MAINTENANCE
To be carried out exclusively by skilled persons after the power supply to the motor
has been interrupted.
Periodically, when the gate is standstill, clean and keep the guide free from stones and dirt.
REMOVE THE TRANSPARENT COVER FROM THE TOP OF THE
ELECTRONIC BOARD BY UNSCREWING ITS 3 SCREWS.
