RADIO TRANSMITTER MOON
* MOON 433 (433,92MHz) - 2CH Code ACG6081 - 4CH Code ACG6082
* Ref. Min. Certificate P.T. of EC inspection N. EMC/97/084
* Min. Authorization P.T. CEPT LPD-I DGPGF/4/2/03/338529/FO/
* EC CERTIFICATE OF COMPLIANCE OF THE KIND
* CERTIFICATE OF CONFORMITY (GERMANY)
* CERTIFICATE EXPERT OPINION (GERMANY)
SPARK ANTENNA
In order to make the systems mentioned above give the best performances, you need to
install an antenna tuned on the frequency of the radio receiver installed.
N.B. Pay attention not to let the central wire of the cable to came Into contact with
the external copper sheath, since this would prevent the antenna from working.
Install the antenna vertically and in such a way the remote control can reach it.
SPARK ANTENNA 433 code ACG5252
SPARK BLINKER with in-built intermittent card code ACG7059
PLATE TO BE CEMENTED code ACG8101
NYLON RACK MODULE 4, with zinc plated angle Iron, In 1mt. bars.
Ideal for gates up to 1,000Kg / 2,200lbs weight
code ACS9000 1mt / 3,28”
code ACS9001 10mt / 32,8” (1mt/3,28” x 10)
NYLON OLIVE code ACG4010
BLOCK
BLOCK KEY SELECTOR FOR WALL-INSTALLATION code ACG1053
BLOCK KEY SELECTOR TO BUILD-IN code ACG1048
MECHANICAL STRIP L=2MT - 6,56 FEET code ACG3010
With double-safety contact, you can cut the length you need.
FIT SYNCRO
FIT SYNCRO PHOTOCELLS FOR THE WALL-INSTALLATION - code ACG8026
The range you can set Is 10÷20mt 49÷100”
You can fit many couples close together thanks to the synchronising circuit.
Add the SYNCRO TRANSMITTER, code ACG8028, for more than 2 photocells couples
(up to 4).
COUPLE OF BUILT-IN BOXES FOR THE FIT SYNCRO code ACG8051
ACCESSORIES
E
N
G
L
I
S
H
Pag. 25 di 36
ACG6081
ACG6082
PUSH-BUTTON FLAT
cod. ACG2013
PROBE
(cod. ACG4665)
The probe detects the motor temperature to operate the heating system under low
temperature conditions (connect to connector J8)
PROBE
