RIB KING EVO - KING EVO Installation Measures

35
Make sure to fasten the
bolt that fixes the piston to
the bracket enabling that
this one can easily rotate.
YES !
The piston must not
change its height during
the different phases of
the mouvement.
NO !
KING EVO - RESPECT THE MEASURES FOR A CORRECT INSTALLATION
9
S1
Z
Y
X
COL - Column attachment KING EVO
KING EVO with 1 mechanical stopper
A
max
α
max
C D
T
max sec
COL
0÷20
110°
120 815
24
S1-X
20÷40 26
40÷60 27
60÷100
105°
29
100÷120 30
S1-Y
120÷140 100° 31
KING EVO with 2 chanical stoppers
A
max
α
max
C D
T
max sec
COL
0÷20
110°
120 775
24
S1-X20÷40 26
40÷60 27
60÷100
105°
26 S2-Y
100÷120 27
S3-Y
120÷140 100° 28
S2
Z Y X
S3
L
C
A
D
α
55
110
Respect the height 55 and make sure that the piston is in horizontal position
G
B
