RIB KING EVO - KING EVO L Installation Measures

36
* In the case of leaf longer than 2,5 metres, an electric lock must be fitted to ensure efficient closing.
If the pillar is too large, and it is not possible to adjust the actuator respecting the measure (B), you must make a niche in the pillar or you have to move the gate to the edge of the pillar.
KING EVO L - RESPECT THE MEASURES FOR A CORRECT INSTALLATION
10
KING EVO L with 1 mechanical stopper
A
max
α
max
B C D
T
max sec
0 140° 120 240
945
38
0÷100 115° 170
160
33
100÷140 110° 200 35
140÷180 105° 250 38
KING EVO L with 2 mechanical stoppers
A
max
α
max
B C D
T
max sec
0÷100 115° 170
160 905
33
100÷140 110° 200 35
140÷180 105° 250 38
110
D
A
C
α
L
55
B
Respect the height 55 and make sure that the piston is in horizontal position
G
B
775
447
KING EVO
CLOSED
OPENED
OUTSIDE OPENING with 2 STOPPERS
905
447
KING EVO L
CLOSED
OPENED
OUTSIDE OPENING with 2 STOPPERS
