Ricoh Aficio MP 6002 - Fax; Basic Procedure for Transmissions (Memory Transmission)

Gate Fold
Applies three folds to create four equal panels (center line main fold, outer panels folding inward
without overlap).
CNP020
1.
Press [Finishing].
2. Press [Fold].
3. Press [Gate Fold].
4. Press [Change].
5. Select [Fold Orientation] and [Print Side].
6. Press [OK] twice.
7. Place the originals, and then press the [Start] key.
Finishing
73
