Ricoh Aficio MP C3002 User Manual

• [Frequent]: Added to the page that is displayed first.
• [AB], [CD], [EF], [GH], [IJK], [LMN], [OPQ], [RST], [UVW], [XYZ], [1] to [10]: Added to the
list of items in the selected title.
You can select [Frequent] and one more key for each title.
8. Press [Auth. Info], and then press [ Next].
9. Press [Specify Other Auth. Info] on the right side of "Folder Authentication".
When [Do not Specify] is selected, the SMB User Name and SMB Password that you have
specified in "Default User Name / Password (Send)" of File Transfer settings are applied.
10. Press [Change] under "Login User Name".
11. Enter the login user name of the destination computer, and then press [OK].
12. Press [Change] under "Login Password".
13. Enter the password of the destination computer, and then press [OK].
14. Enter the password again to confirm, and then press [OK].
15. Press [Folder].
16. Check that [SMB] is selected.
17. Press [Change] or [Browse Network], and then specify the folder.
To specify a folder, you can either enter the path manually or locate the folder by browsing the
network.
18. Press [Connection Test] to check the path is set correctly.
Basic Procedure When Using Scan to Folder
115

Ricoh Aficio MP C3002 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	30 ppm
Print Speed (Monochrome)	30 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Automatic Duplexing	Yes
Copier Resolution	600 x 600 dpi
Fax Capability	Yes
Memory (Standard)	1.5 GB
ADF Capacity	100 sheets
Fax Speed	33.6 kbps
Scanner Type	Flatbed with ADF
Connectivity	USB, Ethernet
Paper Size	A3, A4, A5, B4, B5, Legal, Letter, Executive
Max Paper Size	A3
Operating System Compatibility	Windows, Mac, Linux
Hard Drive	250 GB
