Ricoh Aficio MP C3002 User Manual

Step 3: Specifying access privileges for the created shared folder
If you want to specify access privileges for the created folder to allow other users or groups to access
the folder, configure the folder as follows:
1. Right-click the folder created in above step 1, and then click [Properties].
2. On the [Security] tab, select [Edit...].
3. Click [Add...].
4. In the [Select Users or Groups] window, click [Advanced...].
5. Specify one or more object types, select a location, and then click [Find Now].
6. From the list of results, select the groups and users you want to grant access to, and then
click [OK].
7. In the [Select Users or Groups] window, click [OK].
8. In the [Groups or user names:] list, select a group or user, and then, in the [Allow] column
of the permissions list, select either the [Full Control] or [Change] check box.
9. Press [OK] twice.
Registering an SMB Folder
1. Press the [User Tools/Counter] key.
2. Press [Address Book Management].
3. Check that [Program / Change] is selected.
4. Press [New Program].
5. Press [Change] under "Name".
The name entry display appears.
6. Enter the name, and then press [OK].
7. Press the key for the classification you want to use under "Select Title".
The keys you can select are as follows:
6. Scan
114

Ricoh Aficio MP C3002 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	30 ppm
Print Speed (Monochrome)	30 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Automatic Duplexing	Yes
Copier Resolution	600 x 600 dpi
Fax Capability	Yes
Memory (Standard)	1.5 GB
ADF Capacity	100 sheets
Fax Speed	33.6 kbps
Scanner Type	Flatbed with ADF
Connectivity	USB, Ethernet
Paper Size	A3, A4, A5, B4, B5, Legal, Letter, Executive
Max Paper Size	A3
Operating System Compatibility	Windows, Mac, Linux
Hard Drive	250 GB
