1. Ventilation holes
Prevent overheating.
2. Bypass tray
Use to copy or print on OHP transparencies and label paper (adhesive labels).
3. Paper guides
When loading paper in the bypass tray, align the paper guides flush against the paper.
4. Extender
Pull this extender out when loading sheets larger than A4 , 8
1
/
2
× 11 in the bypass tray.
5. Lower right cover
Open this cover when a paper jam occurs.
Rear and left view
1
1
1
CJS003
1. Ventilation holes
Prevent overheating.
