Page #196 background imageLoading...
Page #196 background image
Using the Document Server
Following describes how to use the Document Server.
Storing Data
Following describes the procedure for storing documents on the Document Server.
Data stored in the machine might be lost if some kind of failure occurs. The manufacturer shall not be
responsible for any damage resulting from loss of data.
Be careful not to let anyone know your password, especially when entering a password or recording
it. Keep any record of your password in a secure place.
Avoid using a single number or consecutive numbers for a password such as “0000” or “1234”,
since the numbers like this are easy to guess, so using them will not provide a worthwhile level of
security.
A document accessed with a correct password remains selected even after operations are complete,
and it can be accessed by other users. After the operation, be sure to press the [Clear Modes] key to
cancel the document selection.
The user name registered to a stored document in the Document Server is to identify the document
creator and type. It is not to protect confidential documents from others.
When turning on the fax transmission or scanning by the scanner, make sure that all other operations
are ended.
File Name
A document name such as “COPY0001” and “COPY0002” is automatically attached to the scanned
document. You can change the document name.
User Name
You can register a user name to identify the user or user group that stored the documents. To assign
it, select the user name registered in the Address Book, or enter the name directly.
Password
To prevent unauthorized printing, you can set a password for any stored document. A protected
document can only be accessed if its password is entered. If a password is set for the documents, the
key icon appears next to the documents.
5. Document Server
194
5

Table of Contents

Other manuals for Ricoh Aficio MP C4000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio MP C4000 and is the answer not in the manual?

Ricoh Aficio MP C4000 Specifications

MP C4000

Power IconPower
power requirements120V, 12A, 60Hz
power consumption1, 500 Watts max.
Printing IconPrinting
output speed40 ppm Full-Color/BW
warm-up time34 seconds
first copy time (Full-Color)6.5 sec.
Paper Handling IconPaper Handling
document feeder capacity100 sheets
input capacityStandard: 2 x 550 sheets + 100-Sheet Bypass Tray
output capacityStandard: 500 sheets Face Down
Printer Controller IconPrinter Controller
CPUIntel Celeron-M 1.0 GHz
memory1 GB RAM and 160 GB HDD
max print resolution1200 x 1200 dpi
Weight and Dimensions IconWeight and Dimensions
dimensions26.4" x 26.7" x 30"
weightLess than 287 lbs. (130 kg)

MP C5000

Power IconPower
power requirements120V, 12A, 60Hz
power consumption1, 500 Watts max.
Printing IconPrinting
output speed50 ppm Full-Color/BW
warm-up time51 seconds
first copy time (Full-Color)5.9 sec.
Paper Handling IconPaper Handling
document feeder capacity100 sheets
input capacityStandard: 2 x 550 sheets + 100-Sheet Bypass Tray
output capacityStandard: 500 sheets Face Down
Printer Controller IconPrinter Controller
CPUIntel Celeron-M 1.0 GHz
memory1 GB RAM and 160 GB HDD
max print resolution1200 x 1200 dpi
Weight and Dimensions IconWeight and Dimensions
dimensions26.4" x 26.7" x 30"
weightLess than 287 lbs. (130 kg)
