2. Base point when placed in the ADF
1. Press [Reduce / Enlarge].
To select a preset ratio on the initial display, press the shortcut reduce/enlarge key.
2. Select a ratio, and then press [OK].
3. Place the originals, and then press the [Start] key.
• You can change reproduction ratios shown on the initial display under Reproduction Ratio in User
Tools. For details about Reproduction Ratio, see “Reproduction Ratio”.
• You can select one of 12 preset ratios (5 enlargement ratios, 7 reduction ratios).
• Following shows the relation between the original and paper sizes at respective scaling factors.
• Metric version
400% (Area ratio 16 times): -
200% (Area ratio 4 times): A5 A3, B6JIS B4JIS
141% (Area ratio 2 times): A4 A3, A5 A4, B5JIS B4JIS, B6JIS B5JIS
122%: A4 B4 JIS, A5 B5JIS
115%: B4 JIS A3, B5JIS A4, B6JIS A5
93%: -
82%: B4 JIS A4, B5JIS A5
2. Basic Copying
54
