Ricoh Aficio MP C4502 User Manual

Standard Printing
• If you send a print job via USB 2.0 while the machine is in Low Power mode or Sleep mode, an
error message might appear when the print job is complete. In this case, check if the document was
printed.
When Using the PCL 6 Printer Driver
1. Click the WordPad menu button in the upper left corner of the window, and then click
[Print].
2. In the [Select Printer] list, select the printer you want to use.
3. Click [Preferences].
4. In the "Job Type:" list, select [Normal Print].
5. In the "Document Size:" list, select the size of the original to be printed.
6. In the "Orientation:" list, select [Portrait] or [Landscape] as the orientation of the original.
7. In the "Input Tray:" list, select the paper tray that contains the paper you want to print
onto.
If you select [Auto Tray Select] in the "Input Tray:" list, the source tray is automatically selected
according to the paper size and type specified.
8. In the "Paper Type:" list, select the type of paper that is loaded in the paper tray.
9. Select [Color] or [Black and White] in the "Color/ Black and White:" list.
10. If you want to print multiple copies, specify a number of sets in the "Copies:" box.
11. Click [OK].
12. Start printing from the application's [Print] dialog box.
Standard Printing
103

Ricoh Aficio MP C4502 Specifications

General

Print Technology	Laser
Maximum Print Resolution	1200 x 1200 dpi
Maximum Paper Capacity	4, 400 sheets
Automatic Duplexing	Yes
Maximum Scan Resolution	600 dpi
Fax Capability	Optional
Maximum Paper Size	12" x 18"
Memory (Standard)	1.5 GB
Hard Drive	250 GB
Copy Resolution	600 x 600 dpi
Print Speed	45 ppm
Standard Paper Capacity	1, 200 sheets
Scanner Type	Flatbed, ADF
Network Connectivity	Ethernet
Functions	Print, Copy, Scan
Copy Speed	Up to 45 ppm (Black/Color)
Fax Speed	33.6 kbps
Operating System Compatibility	Windows, Mac, Linux
