Ricoh Aficio MP C4502 User Manual

1. Press the [Home] key on the top left of the control panel, and press the [Document Server]
icon on the [Home] screen.
CJS113
2. Press [To Scanning Screen].
3. Press [User Name].
4. Specify a user name, and then press [OK].
The user names shown are names that were registered in the Address Book. To specify a name not
shown in the screen, press [Manual Entry], and then enter a user name.
5. Press [File Name].
6. Enter a file name, and then press [OK].
7. Press [Password].
8. Enter a password with the number keys, and then press [OK].
You can use four to eight digits for the password.
9. For double-check, enter the password again, and then press [OK].
10. Place the original.
11. Specify the original scanning conditions.
12. Press the [Start] key.
The original is scanned. The document is saved in the Document Server.
After scanning, a list of stored documents will be displayed. If the list does not appear, press [Finish
Scanning].
7. Document Server
128

Ricoh Aficio MP C4502 Specifications

General

Print Technology	Laser
Maximum Print Resolution	1200 x 1200 dpi
Maximum Paper Capacity	4, 400 sheets
Automatic Duplexing	Yes
Maximum Scan Resolution	600 dpi
Fax Capability	Optional
Maximum Paper Size	12" x 18"
Memory (Standard)	1.5 GB
Hard Drive	250 GB
Copy Resolution	600 x 600 dpi
Print Speed	45 ppm
Standard Paper Capacity	1, 200 sheets
Scanner Type	Flatbed, ADF
Network Connectivity	Ethernet
Functions	Print, Copy, Scan
Copy Speed	Up to 45 ppm (Black/Color)
Fax Speed	33.6 kbps
Operating System Compatibility	Windows, Mac, Linux
