44
Print Cartridge
Hold the print cartridge and shake it
from side to side five or six times.
Even distribution of toner within the bottle
improves print quality.
Slide the print cartridge in
horizontally. When the cartridge can
go no further, raise it slightly and
push it fully in. Then push down
on the cartridge until it clicks into
place.
Carefully push up the front cover until it closes. Be careful not
to trap your fingers.
After closing the front cover, wait until the initial screen is displayed.
Put the protective sheet you
removed in step 5 on the old print
cartridge. Then, put the old print
cartridge into the bag, and then put
it into the box.
• Make sure to cover the old print cartridge with the protective sheet for recycling and
environmental purposes.
• Comply with the print cartridge recycling program, whereby used print cartridges are collected
for processing. For details, ask your sales or service representative.
BSP038S
BSP039S
BSP117S
Replacing the Print Cartridge
