Ricoh Aficio SP C730DN User Manual

2. Slide both sides of the paper guide outward, and then load paper print side down until it
stops.
1
1
2
CSJ126
3. Adjust both sides of the paper guide to match the paper width.
CSJ127
• When using the bypass tray, it is recommended that you set the paper direction to .
• Before loading Postcard or 148 × 200 mm paper, straighten any curls within 2 mm (0.1 inch)
upward and 0 mm (0 inches) downward on the tray.
• Letterhead paper must be loaded in a specific orientation. For details, see p.38 "Loading
Orientation-Fixed Paper or Two-Sided Paper".
• You can load envelopes into the bypass tray. Envelopes must be loaded in a specific orientation.
For details, see p.40 "Loading Envelopes".
Loading Paper into the Bypass Tray
37

Ricoh Aficio SP C730DN Specifications

General

Brand	Ricoh
Model	Aficio SP C730DN
Category	Printer
Language	English
