B003/B004/B006/B007 ii SM
3.2 BIT SWITCHES.......................................................................................3-10
3.2.1 SYSTEM SWITCHES.....................................................................3-10
3.2.2 SCANNER SWITCHES………………………………………………...3-22
3.2.3 PRINTER SWITCHES....................................................................3-27
3.2.4 COMMUNICATION SWITCHES.....................................................3-32
3.2.5 G3 SWITCHES...............................................................................3-41
3.2.6 G3-2 SWITCHES............................................................................3-49
3.2.7 G3-3 SWITCHES............................................................................3-54
3.2.8 G4 INTERNAL SWITCHES ............................................................3-55
3.2.9 G4 PARAMETER SWITCHES........................................................3-62
3.3 NCU PARAMETERS ...............................................................................3-65
3.4 DEDICATED TRANSMISSION PARAMETERS......................................3-76
3.4.1 PROGRAMMING PROCEDURE....................................................3-76
3.4.2 PARAMETERS...............................................................................3-77
3.5 SERVICE RAM ADDRESSES.................................................................3-81
DETAILED DESCRIPTIONS
4. DETAILED SECTION DESCRIPTIONS ........................................4-1
4.1 OVERVIEW………………………………………………………………………4-1
4.2 BOARDS ...................................................................................................4-2
4.2.1 FCU ..................................................................................................4-2
4.2.2 NCU (US) .........................................................................................4-4
4.2.3 NCU (EUROPE/ASIA) ......................................................................4-5
4.2.4 SG3 BOARD.....................................................................................4-6
4.2.5 SIG4 BOARD....................................................................................4-7
4.3 VIDEO DATA PATH ..................................................................................4-8
4.3.1 TRANSMISSION ..............................................................................4-8
4.3.2 RECEPTION...................................................................................4-11
4.4 FAX COMMUNICATION FEATURES .....................................................4-13
4.4.1 PERSONAL/INFORMATION/TRANSFER BOXES ........................4-13
4.4.2 MULTI-PORT..................................................................................4-16
4.4.3 DOCUMENT SERVER ...................................................................4-17
4.4.4 LAN FAX DRIVER ..........................................................................4-18
4.5 FIRMWARE HISTORY…………………………………………………………4-20
4.5.1 FAX OPTION FIRMWARE MODIFICATION HISTORY……………..4-20
4.6 SOFTWARE HISTORY.………………………………………………………..4-22
4.6.1 FAX OPTION SOFTWARE MODIFICATION HISTORY…………………4-22
SPECIFICATIONS
SPECIFICATIONS ............................................................................5-1
1 GENERAL SPECIFICATIONS .....................................................................5-1
2 CAPABILITIES OF PROGRAMMABLE ITEMS............................................5-3
3 MACHINE CONFIGURATION......................................................................5-4
Rev. 02/2002
