Ricoh FAX1120L Field Service Manual

5.System Maintenance
150
Fax Service Test (Only for Fax Models)
Fax Service Test Menu
Entering the Fax Service Test Menu
Turn on the machine while pressing the [Home] key, and hold on pressing it until displayed "Fax Service
Test".
Selecting an Item
Select the item which you want to execute.
Exiting the Fax Service Test Menu
Press [Exit].
Menu List
Menu
Description
Off-Hook Test
On Hook
Executes the on hook test.
Off Hook
Executes the off hook test
CED Test
Executes the CED test.
CNG Test
1100 Hz
Executes the CNG test
ANSam Test
Executes the ANSam test.
Ring Tone Test
Executes the ring tone test.
DTMF Test
Tone [0] to [9]
Executes the DTMF tone 0 to 9 test.
Tone [*]
Executes the DTMF tone * test.
Tone [#]
Executes the DTMF tone # test.
Tone Stop
Executes the Stop DTMF tone test.
Modem Test
[V34] 33600 Bps
Generates the [V34] 33600 bps signal.
[V34] 28800 Bps
Generates the [V34] 28800 bps signal.
[V17] 14400 Bps
Generates the [V17] 14400 bps signal.
[V17] 12000 Bps
Generates the [V17] 12000 bps signal.
[V17] 9600 Bps
Generates the [V17] 9600 bps signal.
[V17] 7200 Bps
Generates the [V17] 7200 bps signal.
[V29] 9600 Bps
Generates the [V29] 9600 bps signal.
[V29] 7200 Bps
Generates the [V29] 7200 bps signal.
[V27] 4800 Bps
Generates the [V27] 4800 bps signal.
[V27] 2400 Bps
Generates the [V27] 2400 bps signal.
[V21] 300 Bps
Generates the [V21] 300 bps signal.
