OTHER COPY IMAGE ADJUSTMENTS
Mode No. Description Data
SP2-101-001 Leading Edge Erase Margin 0-32 (0.5 mm/step)
SP1-001 Registration 0-32 (0.5 mm/step)
SP4-008 Vertical Magnification 0-32 (0.1%/step)
SP4-101 Horizontal Magnification 0-32 (0.1%/step)
SP4-103 Focus Adjustment 0-150 (0.05 mm/step)
SP4-011 Lens Horizontal H.P. Adjustment 0-32 (0.2 mm/step)
3.3 DATA DISPLAY
The following table shows SP modes for displaying adjusted or detected values,
or counter values.
Mode No. Displayed Data Mode No. Displayed Data
1-106 Fusing Temperature 7-004 Initial Copy Counter Setting for
RDS/CSS
2-002 Drum Charge Roller Voltage
2-206 Development Bias 7-101 Total Copies by Paper Size
2-215 TD Sensor Output 7-203 Drum Counter
2-220 TD Sensor Initial Output 7-204 Feed Unit Counter
2-802 Drum Charge Roller Temperature 7-205 DF Counter
3-002 ID Sensor Initial Setting 7-206 Staple Counter
3-103 ID Sensor Output 7-301 Total Copies by Magnification
3-106 Initial V
LP/VLG 7-401 SC Total Counter
3-107 Current V
LP/VLG 7-402 SC Counter by Each Service Call
3-111 Current V
RP/VRG 7-501 Total Jam Counter
4-002 Exposure Lamp Voltage 7-502 Total Copy Paper Jam Counter
4-202 ADS Initial Gain 7-503 Total Original Jam Counter
4-203 ADS Actual Gain 7-504 Total Jams by Location
5-402 User Code Counter 7-505 Total Original Jams by Location
5-408 Number of Registered User Codes 7-801 Main ROM Version
7-001 Total Operation Time 7-803 PM Counter
7-002 Total Original Counter
7-003 Copy Charge Counter for RDS/CSS
FT5535/4527/4522 4-52 FSM
