4. TEST POINTS (MAIN CONTROL BOARD)
Number Label Monitored Signal
TP1 (RXB) RXB
TP2 (TXB) TXB
TP3 (TXA) TXA
TP4 (TXS) TXS
TP5 (RXS) RXS
TP6 (GND) Ground
TP7 (+5 V) +5 V
TP8 (TXL) TXL
TP9 (P-SENSOR) ID sensor output
TP11 (TRANS-FB) Transfer current feed-back voltage
TP12 (LAMP) Exposure lamp voltage feed-back voltage
TP13 (T-SENSOR) Toner density sensor output
TP14 (ADS) Auto image density sensor output
TP15 (RXA) RXA
TP16 (CHA-FB) Drum charge roller feed-back voltage
TP17 (DEV-BIAS) Development bias feed-back voltage
TP18 — Drum charge thermistor output
TP19 — Not used
TP20 — Secondary fusing thermistor output
TP21 — Main fusing thermistor output
FSM 4-53 FT5535/4527/4522
