6.7 PAPER FEED CLUTCH REPLACEMENT (A157/A159/A160)
1. Remove the paper feed roller assembly (see "Paper Feed Roller
Replacement").
2. Remove the rear cover (see "Outer Cover Removal").
3. Remove the paper feed clutch assembly [A] (3 screws, 1 connector).
4. Remove one E-ring [B] and the pull out the shaft [C].
5. Remove the paper feed clutch [D] (1 connector).
[C]
[D]
[A]
FT5535/4527/4522 5-38 FSM
