6.3 FRICTION BELT REPLACEMENT
1. Turn off the main switch and open the feed-in cover [A].
2. Gently pull up the friction belt assembly [B] and remove it from the shaft.
3. Replace the friction belt [C].
[A]
[B]
[C]
FSM 7-11 FT5535/4527/4522
