3. Remove the two plastic caps [A] from the copier left cover with nippers.
4. Remove the rear cover [B] of the sorter stapler.
5. Release the lock lever [C] of the sorter stapler and unhook the sorter stapler
mounting frame [D] while releasing the stopper [E] as shown.
[A]
[C]
[B]
[E]
[D]
FT5535/4527/4522 10-10 FSM
