6.3 BIN REPLACEMENT
1. Remove the proof tray [A] (1 screw).
2. Remove the sorter stapler from the copier.
3. Remove the jogger bar [B] as shown.
4. Remove the upper securing screw of each bin link [C] (1 screw each).
[A]
[B]
[C]
FSM 10-17 FT5535/4527/4522
