6.6.2 Bin Sensor Adjustment
1. Turn on DIP SW100-5 [A]
2. If LED100 [B] is lit, turn VR100 [C] counterclockwise until LED100 turns off.
3. Turn VR100 clockwise until LED100 just turns on.
4. Turn off DIP SW100-5.
[C]
[B]
[A]
FSM 10-27 FT5535/4527/4522
