4. Remove the rear cover. (See "Replacement and Adjustment - Inner and
Outer Covers".)
5. Pull out the carrying handles [A].
6. Before installing the heater, bind the heater harness [B] with insulating tape
[C] as shown to prevent the heater harness from being damaged by the edge
of the copier main frame.
7. Pass the connector [D] through the opening [E] in the copier main frame.
8. Mount the heater [F] on the bottom of the copier main frame (2 screws).
9. Pass the two projections [G] through the opening [H] in the copier main
frame, then mount the heater cover [I] on the bottom of the copier main frame
(1 screw).
CAUTION
The heater cover is necessary, because the surface of the heater
becomes very hot.
10. Insert the clamp [J] into the rear frame, and join the connectors [K].
11. Clamp the harness [L] to the two clamps [J] and [M] as shown to prevent the
harness from touching the carrying handle.
NOTE: Tell the customer that even when the copier main switch is turned off,
the copier power cord should be plugged in. Otherwise, the tray
heater will not function.
Rev. 7/95
FT5535/4527/4522 3-20 FSM
