1-Bin Tray Unit (D574)
D117/D118 2-28 SM
2.4 1-BIN TRAY UNIT (D574)
2.4.1 COMPONENTS CHECK
Check the quantity and condition of the components against the following list.
No. Description Q’ty
1 1-Bin Tray Unit 1
2 Tray 1
3 Binding Screw (M3 x 6) 2
4 Screw (M3 x 10) 18
5 Grounding plate 1
6 Front Right Cover*1 1
7 Left Cover*1 1
8 Rear Upper Cover*2 1
9 Rear Upper Right Cover*2 1
10 Mounting Frame 1
11 Mounting Frame Junction 1
12 Ferrite Core Cover 1
13 Ferrite Core 1
-
Installation Procedure (for service persons) (This
procedure)
To Next Page
