3 Hang-up decision when a negative code
(RTN or PIN) is received during G3
immediate transmission
0: No hang-up, 1: Hang-up
0: The next page will be sent even if RTN or PIN
is received.
1: The machine will send DCN and hang up if it
receives RTN or PIN.
This bit is ignored for memory transmissions or if
ECM is being used.
4-7 Not used Do not change these settings.
Communication Switch 03 (SP No. 1-104-004)
No Function Comments
0-7 Maximum number of page
retransmissions in a G3 memory
transmission
00 - FF (Hex) times.
This setting is not used if ECM is switched on.
Default setting - 03(H)
Communication Switch 04 (SP No. 1-104-005)
No Function Comments
0 Remote mode switch (TEL mode)
0: Disable
1: Enable (Active)
Set this bit to ON when you wish to switch TEL
mode to FAX mode remotely.
1 Remote mode switch (FAX mode)
0: Disable
1: Enable (Active)
Set this bit to ON when you wish to turn on the
remote mode switch after automatic reception
with FAX mode.
2 Remote mode switch (AUTO mode)
0: Disable
1: Enable (Active)
Set this bit to ON when you wish to turn on the
remote mode switch after automatic reception
with AUTO mode.
3-7 Not used Do not change the settings.
Communication Switch 05 (SP No. 1-104-006)
No Function Comments
0-3 Remote mode switch number
00-09 (0-9:HEX)
Enter the number to switch between TEL/FAX
modes using the external phone.
Bit Switches – 3
