3. Paper guides
When loading paper in the bypass tray, align the paper guides flush against the paper.
4. Bypass tray
Use to copy or print on thick paper, OHP transparencies, envelopes, and label paper (adhesive labels).
5. Extender
Pull this extender out when loading A4 , 8
1
/
2
× 11 or larger size paper in the bypass tray.
6. Lower right cover
Open this cover when a paper jam occurs.
7. Lower paper tray right cover
Open this cover when a paper jam occurs.
8. Right cover
Open this cover to remove jammed paper fed from the paper tray.
Guide to Components (mainly North America)
• Do not obstruct the machine's vents. Doing so risks fire caused by overheated internal
components.
