5. [Check Status] key
Press to check the machine's system status, operational status of each function, and current jobs. You can also
display the job history and the machine's maintenance information.
6. Data In indicator (facsimile and printer mode)
Flashes when the machine is receiving print jobs or LAN-Fax documents from a computer. See Fax and Print.
7. Fax indicator
Indicates the status of the fax functions. Flashes during data transmission and reception. Stays lit when
receiving a fax via Confidential or Substitute Reception.
8. [Menu] key
Displays the menu screen while Screen Features are enabled or applications available only on the Smart
Operation Panel are used.
9. [Return] key
Press this key to return to the previous screen while Screen Features are enabled or applications available only
on the Smart Operation Panel are used.
10. Media access lamp
Lights up when a memory storage device is inserted in the media slot.
11. Media slots
Use to insert an SD card or a USB flash memory device.
Guide to the Names and Functions of the Machine's Control Panel (When Using the Smart Operation Panel)
45
