Ricoh MP C6502SP System Maintenance

014
T-Edge Erase (1-Pass): Front *ENG [-5.0 to 5.0 / -1.5 / 0.1 mm/step]
Executes Front T-Edge Regist Adjustment.
•
Value increase: Increases Image T-Edge.
• Value decrease: Delete Image T-Edge.
Corrects it into the maximum value within adjustable range if the value which exceeds the
range is set. The previous setting value remains if setting is finished without fixing it. Sets the
initial value for -1.5mm instead of 0mm considering Original.
015
T-Edge Erase (1-Pass): Rear *ENG [-5.0 to 5.0 / -1.5 / 0.1 mm/step]
Executes Rear T-Edge Regist Adjustment.
•
Value increase: Increases Image T-Edge.
• Value decrease: Delete Image T-Edge.
Corrects it into the maximum value within adjustable range if the value which exceeds the
range is set. The previous setting value remains if setting is finished without fixing it. Sets the
initial value for -1.5mm instead of 0mm considering Original.
6009 [ADF FreeRun]
001
Free Run Simplex Motion ENG
[- / - / -]
[Execute]
Free Run Simplex Motion starts when an original is set in ADF.
002
Free Run Duplex Motion ENG
[- / - / -]
[Execute]
Free Run Duplex Motion starts when an original is set in ADF.
003
Free Run Stamp Motion ENG
[- / - / -]
[Execute]
Free Run Stamp Motion starts when an original is set in ADF.
6010
[Stamp Position Adj.]
Adjusts Stamp Position.
•
Value increase: Shifts Stamp Position to the side of Original Trailing Edge.
• Value decrease: Shifts Stamp Position to the side of Original Leading Edge.
001 - *ENG [-5.0 to 5.0 / 0.0 / 0.1 mm/step]
4. Main SP Tables-6
