Taurus-C1 Training
205
Slide 205
Where to Adjust Skew and Side-to-side
Registration?
You can adjust at any junction between units
except at the following locations:
Input to the Buffer Pass Unit
Input to the Trimmer Unit
Procedure: Service Manual, Installation, Common
Procedures, Skew and Side-to-side Registration
The procedure is the same as for the B-C4 series. The locations of the
adjustment scales and the spacers are shown in the service manual.
¾ Basically, the peripherals which have a connecting bracket for the
adjustment need to be adjusted to the upstream machine.
There are two scales at the exit of the multi-folding unit. One is above the proof
tray, and one is at the exit from the folder to the next downstream peripheral.
