Ricoh PRO C751 - Page 211

Taurus-C1 Training
211
Slide 211
Adjusting the Skew
 Insert spacers below the adjustment bracket.
 The service manual shows you where to find the spacers inside the
machine.
Adjustment
Bracket
Spacer
Spacer
 If the trailing edge skews towards the rear, insert the spacer at the rear side of
the machine.
