Ricoh PRO C751 - Page 237

Taurus-C1 Training
237
Slide 237
ITB Unit: Pulling it Out
 There are two stop positions, as shown above.
 First stop position [A]
 Second stop position [C]
» You must depress the rail release levers [B] on both sides of
the ITB unit tray before you can pull it out to the 2
nd
stop
position.
No additional notes
