ITB Unit: Re-installation
Before you push the ITB unit into the machine:
Make sure handle B3 [A] below the ITB unit tray is down.
You cannot push the ITB unit tray into the machine if this
lever is up.
You must depress the rail lock levers [B] on both sides of
the tray. (The rail locks engage automatically when the ITB
tray is pulled out completely.
